Dej Saib Xyuas Rau Cov Hluav Taws Xob Hluav Taws Xob
Kev saib xyuas dej rau kev tua hluav taws yog phau ntawv tswj nrog ob lub log los hloov lub viav vias ntsug thiab kab rov tav. Handwheels luv luv thiab siv qhov chaw me me, qhov no tuaj yeem txuag tau qhov chaw me me rau kev txhim kho cov dej saib rau kev tua hluav taws.
Cov lus qhia ntawm qhov ntsuas dej no rau kev tua hluav taws raws li hauv qab no.
Kev khiav dej num yog los ntawm 1800 LPM mus rau 3000 LPM, nrog rau cov lus sib dhos-cov lus qhia nozzle, tus nqi ntws tuaj yeem kho tau, thaum cov qauv jetting yog tas li -- kwj ncaj.
Kev ua haujlwm siab ntawm lub ntsuas dej no rau kev tua hluav taws yog 10 Bar, thiab qhov max. Jetting ntau ntawm cov saib no tuaj yeem ncav cuag 65 meters ntawm 10 Bar.
Txoj kev txav ntsug ntawm qhov ntsuas dej no tuaj yeem ncav cuag -45 degree rau +90 degree, thiab kab rov tav rotaion ntawm lub ntsuas dej no yog 360 degree . Tau kawg, cov lus tsa suab yog hloov tau, nws tuaj yeem hloov ntawm koj tus kheej rau koj qhov kev thov.
Lub qhov hluav taws xob loj yog 2.5 "NH txiv neej xov, qhov inlet yog 4" BS4504 flange, thaum lwm tus qauv flange muaj.
Dej saib rau hluav taws fighitng system yog SS304 stainless hlau kev tsim kho thiab lub nozzle & handwheel yog ua los ntawm cov tawv coated anodized aluminiun alloy.
Qauv nab npawb | PS30-50SHT |
Tus nqi ntws | 1800-3000 LPM kho tau |
Ua Haujlwm Siab | 10 Bar |
Max. Mus txog @ 10 bar | 65 m @ 3000 LPM |
Max Range Ntawm Saib | -45 degree rau +90 degree Vertically, 360 degree tig |
Txoj Kev Loj | 2.5 "(65mm) |
Saib xyuas qhov hluav taws xob | 2.5 "(65mm) NH txiv neej xov |
Saib xyuas Inlet | Flange 4 "BS4504 yog tus qauv, lwm tus qauv flange muaj |
Khoom siv | Saib - SS304 stainless hlau Nozzle & Tes log - Aluminium alloy |
Cov khoom tseem ceeb:
FAQ:
Q: Koj puas muab kev lees paub rau cov khoom?
Yog lawm, peb muab 1 xyoo warranty rau peb cov khoom.
Q: Kuv puas tuaj yeem muaj tus qauv txiav txim?
Yog lawm, peb txais tos cov qauv txiav txim los kuaj thiab kuaj xyuas qhov zoo. Cov qauv sib xyaw ua ke tau txais.
Q: Yuav ua li cas txog lub sijhawm khoom xa tuaj?
Qauv xav tau 7-15 hnub, lub sijhawm tsim khoom loj xav tau 30-40 lub lis piam rau kev txiav txim kom muaj nuj nqis ntau dua 1 lub thawv.
Cov ntaub ntawv xaj xaj:
Nyob zoo cov neeg muas zaub,
Ua ntej kev txiav txim, thov hu rau peb pab neeg muag khoom los tham txog kev txiav txim cov ntaub ntawv, xws li Model Number, Flow Rate, Material, Control Ways, Package, Etc.
Yog tias koj muaj lwm yam kev xav tau lossis xav paub ntau ntxiv txog peb cov khoom, txais tos hu rau thiab. Peb pab neeg muag khoom thiab Technical Department txaus siab pab txhawb koj.
Cim npe nrov: dej saib rau hluav taws sib ntaus system, Suav teb, manufacturers, lwm tus neeg, lag luam wholesale, nqe
1) 304 Stainless Hlau tsim;
2) Tus nqi ntws: 30-50 LPS (Stack Tip);
3) Jetting qauv: Ncaj kwj;
4) 360 degree tig kab rov tav;
5) -45 degree rau +90 degree nce vertically;
6) Flange tus qauv: BS4504, ANSI150, GB, thiab lwm yam.
